CONTEC Shot Blaster – Hornet

The smallest CONTEC® Shotblaster!

The HORNET is a tenacious, yet highly versatile shotblaster. It is extremely well suited for applications where power requirements are a potential issue. The HORNET is lightweight and highly manoeverable yet still capable of delivering a superbly  prepared surface.

  • Shotblasting on  small Areas
  • Easy to handle, low weight, ready in minutes
  • Ready for Action in Minutes
  • Dustfree
  • Made for small Floors with difficult Access (Balkonies, Garages und Cellars)
  • Max. 10 or 20 A single Phase for 230 or 110/115 V supply
  • Easy Transport

Description

Technical Data

Download Datasheet

Working Width 200 mm
Voltage 115/230 V
Frequency 50 Hz
Phase 1
Current Consumption 20/10 A
Motor Rating 2.1/2.2 kW
Motor nominal Current 20/10 A
Motor Rotation Speed 8500 rpm
Weight 50 kg
Height 100-108 cm
Length 73-78 cm
Width 31.5 cm
Recommended Dust Collector CDM 2000 / CDM 3000
Dust Port Diameter 70 mm

Accessories

Magnetic Brush

The Magnetic Brush collects any shot which the machine may lose on the floor. The shot can then be used again.  The Magnetic Brush is available in two Widths, 50 and 70 cm.

Tools

Blast Wheel HORNET

Manganese Steel for Blade Wheel


Shot Cage (small)

By turning the Shot Cage the blast pattern can be adjusted


Shot

Different floors need different sizes of shot. The Technical Data spreadsheet below gives further information about the most common sizes of shot and the applications they are best suited for.
