BLASTRAC BDC-133MUD DUST COLLECTOR
Usually in stock
BDC-133MUD DUST COLLECTOR
Request a quote
Pricing for this machine depends on configuration and delivery. Add it to your quote list and we will come back to you.
Specifications
| Airflow | 390 m³/h |
|---|---|
| Vacuum | 211 hPa |
| Dust Extraction Motor | 3 Independent Motors |
| Weight | 73 kg |
| Working Position LxWxH | 800 x 600 x 1650 mm |
| Transport Position LxWxH | 800 x 600 x 1300 mm |
| Filter | M-Class Star Filter, Manual shaker on top |
| Rated power input | 3 kW |
| Voltage | 230 V |
| Frequency | 50/60 Hz |
| Rated Current | 13 A |
| Pins | 1 ph |
| Dust Hose Inlet | Ø 70 mm |
| Dustbin | Endless bagging system, Adjustable capacity up to 25 kg |
| Noise Level | 71 dB(A |
Product description
BDC-133MUD DUST COLLECTOR
HEAVY-DUTY DUST COLLECTION SYSTEM
The Blastrac BDC-133MUD is a heavy-duty dust collection system completely M-class certified. The BDC-133MUD is ideally suited for use with medium size shot blasting, grinding, polishing, and scarifying machines. It comes equipped as standard with an M-class star filter and with a Longopac bagging system, which is easy to mount and handle. Because of this system, there is no contact between the operator and the dust, creating a safe working environment.
ADVANTAGES OF THE BDC-133MUD DUST COLLECTOR:
M-class certified dust collector
Only available with the Longopac system
Easy to clean using the manual hand shaker
Up & Down system (transport & working positions)
