BLASTRAC BMP-4000RC SCARIFIER

BMP-4000RC SCARIFIER

Working Width: Scarifying – Ø335 mm, Sawing – Ø380 mm
Weight: 1550 kg excl. drum
Dimension LxWxH: 1995 x 840 x 1660 mm
Rated Power Input: 30 kW
Voltage: 400 V
Frequency: 50 Hz
Rated Current: 63 A
Pin: 3 ph
RPM: Scarifying – 300 rpm, Sawing – 1800 rpm
Dust Hose Connection Ø: 150 mm
Noise Level: 98 dB(A)
Rotate: Remote controlled (Hydraulically driven)
Surface: Concrete, Stone, Asphalt

Description

BMP-4000RC SCARIFIER

A HEAVY-DUTY REMOTE CONTROLLED SCARIFIER

The Blastrac BMP-4000RC is a new heavy-duty remote-controlled sawing (shaving) and milling machine ideally suited for large milling and sawing applications, for example, road construction and industrial flooring. The BMP-4000RC is a multifunctional machine. By changing the hydraulic motor you can easily swap the milling and the sawing technology. It has a double, hydraulic micrometric adjustment to set the working depth, to work very precisely, and eliminate the risk of underground deterioration. Due to its increased weight, it allows you to generate more efficient and precise sawing and milling actions.

The BMP-4000RC scarifier is almost dust free when connected to the appropriate Blastrac dust collection system. Blastrac has designed a full range of scarifiers and cutters, which give the opportunity to process any floor and specific application.



ADVANTAGES OF THE BMP-4000RC SCARIFIER:

  • HYDRAULICALLY DRIVEN With variable speed, forward and reverse, this heavy-weight scarifier can be driven without the scarifying drum engaged.
  • COMPACT SIZE Despite appearances, the BMP-4000RC fits through every door opening due to its unbelievably narrow width of only 840 mm. In addition, it comes equipped as standard with an ammeter and front and back working lights.
  • PRECISE HEIGHT ADJUSTMENT Both hydraulic cylinders have a depth sensor indicator for a precise height adjustment while working. In addition, a display gives information about height adjustment and shows information about the machine.
  • REMOTE CONTROLLED MACHINE The BMP-4000RC is a remote-controlled scarifier made for the toughest scarifying applications.
  • DUST HOSE CONNECTION Dust hose connection is Ø150 mm for a dust-free job site.
  • OPTIONAL LASER SYSTEM The BMP-4000 can be equipped with a laser system that keeps the machine leveled automatically. It also tracks the gradient of the flooring on a user-friendly screen.
