BLASTRAC BWFC-CG150 FLOOR & WALL CHASER

BWFC-CG150 FLOOR & WALL CHASER

Weight: 7.2 kg
Dimensions LxWxH: 365 x 220 x 288 mm
Rated Power Input: 2.5 kW
Voltage: 230 V
Frequency: 50/60 Hz
Rated Current: 16 A
Pin: 1 ph
RPM: 6500 rpm
Max Blade Diameter: Ø150 mm
Max Depth of Cut: 50 mm
Max Channel Width: 47 mm
Dust Hose Connection Ø: 36 mm
Noise Level: 95 dB(A)
Vibration: 5.0 m/s²
Surface: Concrete, Stone & Bricks

Description

BWFC-CG150 FLOOR & WALL CHASER

POWERFUL FLOOR & WALL CHASER FOR CONCRETE, BRICKS.

The Blastrac BWFC-CG150 is a powerful floor and wall chaser specifically designed for cutting double slots and channels in reinforced concrete, brick, and similar materials. It features a dust local exhaust with fully enclosed blades for dust-free operations.

The BWFC-CG150 is equipped with 6 rollers in order to keep the base well supported for smooth guidance over slight surface irregularities. The blades are very easy to change and different settings can be mounted thanks to a full set of spacers for both 2 blade and 5 blade set-ups.

This chaser has a LED indicator light for optimizing cutting efficiency with overload and overheat warnings. In addition, the motor is equipped with advanced protection including soft start, overload, and thermal protection. It is possible to adopt an optional guide rail system to provide maximum convenience and reduce human error.



ADVANTAGES OF THE BWFC-CG150 FLOOR & WALL CHASER:

  • MULTIPLE BLADE SETTINGS
    With the BWFC-CG150, you are able to adapt different blade settings depending on the number of spacers you use: 2 blade and 5 blade set-ups.
  • DUST-FREE
    Due to its local dust exhaust, the BWFC-CG150 is dust-free when connected to the appropriate Blastrac dust collector.
  • LED INDICATOR
    The BWFC-CG150 has a LED indicator to optimize cutting efficiency. This LED turns red when the machine is overloaded or overheated.
  • BUILT-IN LASER
    The Blastrac BWFC-CG150 floor and wall chaser feature a built-in laser on the front in order to assist the operator to create consistent straight cuts.
