Caisson
CAISSON Colourmeter (FMG-30)
Usually in stock
The colorimeter FMG-30 is used to measure colors
Request a quote
Pricing for this machine depends on configuration and delivery. Add it to your quote list and we will come back to you.
Specifications
| Average working time | up to 20 hours (with new batteries) |
|---|---|
| illuminant | CIE standard illuminant D65, color temperature 6 500 K |
| Illuminating system | 45 ° / 0 ° |
| Power Supply | 2 AA batteries |
| Packaging | Plastic suitcase |
| mass | 162g |
| Dimensions (L x W x H) | 128mm x 79mm x 25mm |
Product description
It allows the measurement of the difference between the measured sample and the sample. The result of the measurement is two colors that most closely match the selected color palette and the percentage of RGB color areas that make up the color. The vertical construction of the measuring device enables the measurements to be carried out on small areas.
The Paint Checker FMG-30 provides measurements of the sample in comparison to the following color registers: Ral Classic, Ral Effect, Ralik Design, Sikkens 5051, NCS, Pantone, PPG The Voice of Color and PPG Chromatic and Caparol 3D-System PLUS.
Technically
Average working time
up to 20 hours (with new batteries)
illuminant
CIE standard illuminant D65, color temperature 6 500 K
Illuminating system
45 ° / 0 °
power supply
2 AA batteries
packaging
Plastic suitcase
mass
162g
Dimensions (L x W x H)
128mm x 79mm x 25mm
